    Intense Carbine 29 Factory Frame - Blue - 2020 Blue Medium

Intense

Intense Carbine 29 Factory Frame - Blue - 2020

Intense Carbine 29 Factory Frame - Blue - 2020

Regular price $2,999.00
Sale price $2,999.00
Intense Logo

EXTRA 10% OFF THIS ITEM

Use Code EVERYTHING10
Limited Time Only
Color
Size

Product ID: GM102420-08

Earn rewards points on this item / Join Now
Out of stock


Shop all Intense   |   Shop all Full Suspension Frames

View full details

Description

Intense Carbine 29 Factory Frame - 2020

The Carbine Factory frameset comes with an optimized UD Carbon fiber front and rear triangle, a carbon top link and steel hardware.

  • TRAVEL (FRONT/REAR): 160mm/155mm
  • WHEEL SIZE: 29"
  • INCLUDES: Frame, upper & lower links, hardware and shock
  • FRAME WEIGHT: 2,7 Kg. w/out shock
  • HT ANGLE: 65.5 ̊
  • REACH: 410mm/16.1" (Small) // 431mm/17.0" (Medium) // 455mm/17.9" (Large) // 471mm/18.5" (XL)
  • FRAME: Carbine 29” Enduro Optimized Carbon Frame. Carbon top link, internal shift, dropper post and brake routing. ISCG05 mounts, flack guard armour, 155mm travel
  • SHOCK: Fox Factory Float X2, 230x60mm (155mm travel), 2-position (open/firm)

Features

FIND YOUR SIZING



GEOMETRY (MM / INCH)

SIZE Small Medium Large Extra Large
A: SEAT TUBE LENGTH 385
15.2
418
16.5
448
17.6
483
19.0
B: EFFECTIVE TOP TUBE 603
23.7
627
24.7
655
25.8
675
26.6
C: STACK 616
24.3
624
24.6
632
24.9
641
25.2
D: REACH 410
16.1
431
17.0
455
17.9
471
18.5
E: BB HEIGHT 348
13.7
348
13.7
348
13.7
348
13.7
F: BB DROP
0.0

0.0

0.0

0.0
G: HEAD TUBE LENGTH 92
3.6
100
3.9
110
4.3
120
4.7
H: HEAD TUBE ANGLE 65.5 ° 65.5 ° 65.5 ° 65.5 °
I: SEAT TUBE ANGLE 74.0 ° 74.0 ° 74.0 ° 74.0 °
J: STANDOVER HEIGHT 830
32.7
834
32.8
834
32.8
836
32.9
K: CHAINSTAY LENGTH 445
17.5
445
17.5
445
17.5
445
17.5
L: WHEELBASE 1181
46.5
1205
47.4
1233
48.5
1253
49.3
SUGGESTED RIDER HEIGHT
5'0"-5'6"

5'5"-5'10"

5'9"-6'1"

5'11"-6'6"
